KEYENCE Proximity Sensors EX-500 series EX-501

SKU:1351-10360

KEYENCE Proximity Sensors EX-500 series

KEYENCE Proximity Sensors EX-500 series inductive gauging sensor.High accuracy inductive gauging sensor with a resolution of 0.03% of F.S with 0-5V or 4-20mA analog outputs for connecting to external equipment.

Features:

Accurately measures all types of metal targets
Linearity of ± 0.3% of F.S.
Resolution of 0.03% of F.S.
Digital adjustment circuit/Auto-zero function
DIN rail-mountable

KEYENCE Proximity Sensors EX-500 series EX-501

Model		EX-501
Type		Controller
Shape		M8, Threaded, Non-shielded
Measuring range		0 to 1mm 0.04″
Analog output	Output voltage	0 to 5 V (Output impedance: 100 Ω)^*1
	Impedance	100 Ω^*2
	Output current	4 to 20 mA (Applicable load: 0 to 350 Ω)^*1
	Resolution	0.03% of F.S. (RESPONSE = 3, 4)^*2
	Linearity	±0.3% of F.S. (RESPONSE = 2, 3, 4)^*1
	Response time (Response mode)	0.1 ms (RESPONSE = 1), 1 ms (RESPONSE = 2), 10 ms (RESPONSE = 3), 100 ms (RESPONSE = 4)^*2
Disconnection alarm output (N.C.)		NPN: 100 mA max. (40 V), Residual voltage: 1 V max.^*3
Functions		Auto-zero function/Auto-span function, Response time selector function/ Preset metal characteristic memory function, Cable length selector function/Interference suppression function
Temperature characteristics		0.04% of F.S./°C^*2
Temperature fluctuation	Sensor head	0.03% of F.S./°C^4^2
Temperature characteristics	Amplifier unit	0.04% of F.S./°C^*2
Rating	Power voltage	12 to 24 VDC ±10%
	Current consumption.	220 mA max.
Environmental resistance	Enclosure rating	IP67
	Operating temperature range	0 to 50°C 32 to 122°F
	Operating ambient humidity	35 to 85% RH (No condensation)
	Vibration	10 to 55 Hz, double amplitude: 1.5 mm 0.06″, 2 hours in each of X, Y, and Z directions
Weight		Approx 360 g
