Pressure Transmitter

Rosemount 3051S In-Line Pressure Transmitter

The Rosemount 3051S In Line Pressure Transmitters are the

industry leader for Gauge and Absolute pressure measurement.

The in-line, compact design allows the transmitter to be

connected directly to a process for quick, easy and cost

effective installation.

With the Rosemount 3051S Series of Instrumentation, you can

optimize your operation in four critical areas: production,

quality, energy efficiency, and safety and environment.

By leveraging the power of the scalable Rosemount 3051S

across your entire operation, you will minimize process

variability, gain greater process insight, reduce

maintenance and downtime, and meet regulatory demands.

What’s more, it’s easy for your people to use, ensuring you

will realize the full potential of your measurement

investment.

Emerson Rosemount 3051S Series Pressure Transmitter

Pressure types:Gauge pressure,absolute pressure,differential pressure
Measuring range: Gauge: 200Pa-40MPa, Absolute: 2kPa – 10MPa, Differential: 200Pa-10Mpa
Output signal:4-20mA,4~20mA/HART , customer
Reference accuracy:0.075% ,0.05%,
Working temperature:-40-85℃, LCD display unit:-20-70℃
measuring medium:Liquid, gas, or steam level, density and pressure
Media temperature:with silicone oil -40-120℃,
with fluorocarbon oil -10-80℃
Proction class:IP67
OUTPUT SIGNAL:4~20mA two wire,power supply: 10.5-55vdc
4~20mA+HART two wire,power supply: 16.5-55vdc
Diaphragm material:SS316L,Hastelloy C
Stability: ±0.2% URL/5years
Approvals: EX-proof,CE certificate
