Omron Proximity Sensor Y92□ Series





Mounting brackets

There are 4 kinds of special resin mounting brackets.

According to shape selection.

Mounting sleeve (quick installation)

After installing the sleeve and sensor correctly, no need to

adjust the sensor after replacing the sensor.

Protective cover

Cover with protection head.

According to shape selection.

species:
Mounting brackets

Project

The model uses hex bolts for the sensor outer diameter

Y92E-B8 M4 × 20 M8

Y92E-B12 M4 × 25 M12

Y92E-B18 M5 × 32 M18

Y92E-B30 M5 × 50 M30

Note: Please note the effect of the surrounding metal when

using unshielded.

(Please refer to the model for each sensor type.)

Mounting sleeve (quick installation)

Project

Model for sensors

Y92E-G8 E2E / E2E2 M8 Shielded

Y92E-G12 E2E / E2E2 M12 Shielded

Y92E-G18 E2E / E2E2 M18 Shielded

Y92E-G30 E2E / E2E2 M30 Shielded

Note: Do not tighten the nut with too much force.

When tightening, tighten the following tightening torque below the table.

Project

Type nuts for fastening nuts for fixing the body

Y92E-G8 18N · m 6N · m

Y92E-G12 40N · m 15N · m

Y92E-G18 70N · m 15N · m

Y92E-G30 100N · m 30N · m

Protective cover

[Static capacity type proximity sensor can not be used. To
Project

Model cover diameter (thread opening) material suitable for sensor diameter

Y92E-E12 M12 × 1 Polyacetal resin M12 Shield type

Y92E-E18 M18 × 1 M18 Shield type

Y92E-E30 M30 × 1.5 M30 Shielded type

Y92E-E12M M12 × 1 M12 Unshielded

Y92E-E18M M18 × 1 M18 Unshielded

Y92E-E30M M30 × 1.5 M30 Unshielded

Anti-sputter protection cover (cover inside the threaded opening



[Static capacity type proximity sensor can not be used. To
Project

Model for sensor diameter

Y92E-E8-7 M8 shield type

Y92E-E12-7 M12 Shielded

Y92E-E18-7 M18 Shield type

Y92E-E30-7 M30 Shielded type

Note: Please note that excessive screwing will damage the cover.

Anti-sputtering protective cover (inside of the cover without thread opening)



[Static capacity type proximity sensor can not be used. To
Project

Model material suitable for sensor diameter

Y92E-E12-2 silicone rubber M12 shield type

Y92E-E18-2 M18 Shielded

Y92E-E30-2 M30 Shielded

Protective cover (E2V, E2EZ special metal type)

Protective cover dimensions table

Model Item Size (mm) Applicable sensor material

A B (thread opening) C D E

Y92E-VM12 φ13 M12 × 1 0.60 ± 0.05 5 φ9 E2V M12

Corresponding shielding

E2EZ-X2D □ -N

E2EZ-X2D1-M1 (T) (G) J SUS303

Y92E-VM18 φ19 M18 × 1 0.60 ± 0.05 6 φ14 E2V M18

Corresponding shielding

E2EZ-X4D □ -N

E2EZ-X4D1-M1 (T) (G) J

Y92E-VM30 φ31 M30 × 1.5 0.60 ± 0.05 8 φ24 E2V M30

Corresponding shielding

E2EZ-X8D □ -N

E2EZ-X8D1-M1 (T) (G) J

Rated / performance when installing protective cover

Model E2V-X □ E2EZ-X □

project

Detection distance When installing the protective cover, it

is within ± 10% of the range before installation.

Please use within the range of the set distance.

When the protective cover is installed, it is within ± 10%

of the range before installation.

Only M30 type, within ± 15% range.

Please use within the range of the set distance.

Ambient temperature range Action: 5 ~ 55 ℃ (but not condensation)

When stored: -25 ~ 70 ℃ (but not frozen): 0 ~ 50 ℃ (but not frozen condensation)

When stored: 0 ~ 50 ℃ (but not frozen)

Note: For other items, the original rating / performance

with E2V / E2EZ has not changed.

If the use of anti-adhesive to prevent the use of adhesives,

the installation will be more robust.

Nut set

Sensor mounting nut kit. Please order when lost.

According to the use of the sensor shape selection.

Model Item Applicable Sensor Applicable sensor outside

diameter setting contents

Y92E-NWM08-E2E E2E M8 Fastening nut (brass nickel plated): 2 pcs

Toothed washers (galvanized): 1

Y92E-NWM12-E2E M12

Y92E-NWM18-E2E M18

Y92E-NWM30-E2E M30

Y92E-NWM12-E2EQ E2EQ M12 Fastening nut (fluororesin coating,

substrate: brass): 2

Toothed washers (galvanized): 1

Y92E-NWM18-E2EQ M18

Y92E-NWM30-E2EQ M30

Y92E-NWM8 E2FM

E2EF-X M8 fastening nut (SUS303): 2 pcs

Toothed washers (galvanized): 1

Y92E-NWM12 M12

Y92E-NWM18 M18

Y92E-NWM30 M30

Y92E-NWM12-E2EH E2EH M12 Fastening nut (SUS316L): 2

Y92E-NWM18-E2EH M18

Y92E-NWM30-E2EH M30

Y92E-NWM12-E2EZ E2EZ M12 Fastening nut (iron galvanized): 2

pieces

Toothed washers (galvanized): 1

Y92E-NWM18-E2EZ M18

Y92E-NWM30-E2EZ M30

Y92E-NWM08-E2F E2F M8 Fastening nut (polycarbonate): 2 pieces

Y92E-NWM12-E2F M12

Y92E-NWM18-E2F M18

Y92E-NWM30-E2F M30
