Omron Proximity Sensor E2K-F Series
Features:
Efficient space-saving flat type (built-in amplifier,
thickness 10mm)
Can be installed directly to the metal surface
species:
Ontology
Shape Detection Distance Output Type Model / Action Mode
NO NC
Flat type unshielded
472_lu_1_1
10mm DC 3-wire NPN E2K-F10MC1 2M E2K-F10MC2 2M
10mm
* Detection range of variable range
Rating / Performance:
Item Model E2K-F10MC □ -A E2K-F10MC □
Detection distance 10mm (detection range of variable range: 4 ~ 10mm) 10mm ± 10%
Set the distance 0 ~ 7.5mm *
Should be less than 15% of the detection distance
Detects object conductors and dielectrics
Standard detection of objects to ground metal plate 50 × 50 × 1mm
Response frequency 100Hz
Power supply voltage (using voltage range) DC12 ~ 24V
Pulsation (p-p) 10% or less (DC10 ~ 30V)
Current consumption below 10mA (DC24V)
Control output switch capacity NPN open collector, up to 100mA (DC30V)
Residual voltage 1.5V or less (load current 100mA, wire length 2m)
Indicator light (red)
Sensitivity adjustment knob speed 12 rpm –
Operation mode (near detection object) For details, refer to
the timing diagram of “Input Output Section Circuit Diagram”
on the Catalog
Protection circuit reverse connection protection, surge absorption
Ambient temperature range of work, when stored: -10 ~ +55 ° C (no icing, condensation)
Ambient humidity range Operating time: When saving: 35 ~ 85%
RH Operating time: When saving: 35 ~ 95% RH
Temperature of ± 10% of the detection range at + 23 ° C in
the temperature range of -10 ~ + 55 ° C
The voltage is within ± 10% of the rated power supply
voltage, the rated power supply voltage, the detection
distance of ± 2.5%
Insulation resistance 50MΩ or more (DC500V megger) The
charging unit is integral with the housing
Withstand voltage AC500V 50 / 60Hz 1min charging part
between the whole and the shell
Vibration (durable) 10 ~ 55Hz double amplitude 1.5mm X, Y, Z direction 2h
Impact (durable) 500m / s2 X, Y, Z direction 3 times
Protection structure IEC standard IP64 IEC standard IP66
Connection type wire lead type (standard wire length 2m)
After the quality (after packaging) about 35g
Material shell heat ABS
Detection surface
Accessories manual
* E2K-F10MC □ -A Adjusted to 10mm when the value.
