Omron Chemical Resistant Inductive Proximity Sensor E2FQ Series

Omron Chemical Resistant Sensor E2FQ Series

Features:

All use of fluorine resin, chemical resistance superior performance

The longest detection distance of 10mm
species:
Ontology

Shape Detection Distance Output Type Action Mode Model
shield
1866_lu_1_1
M12 2mm DC 2-wire NO E2FQ-X2D1 2M
DC 3-wire NPN E2FQ-X2E1 2M
M18 5mm DC 2-wire E2FQ-X5D1 2M
DC 3-wire NPN E2FQ-X5E1 2M
AC 2-wire E2FQ-X5Y1 2M
M30 10mm DC 2-wire E2FQ-X10D1 2M
DC 3-wire NPN E2FQ-X10E1 2M
AC 2-wire E2FQ-X10Y1 2M

Rating:
Item Model E2FQ-X2E1
E2FQ-X2D1 E2FQ-X5E1
E2FQ-X5D1
E2FQ-X5Y1 E2FQ-X10E1
E2FQ-X10D1
E2FQ-X10Y1

Detection distance 2mm ± 10% 5mm ± 10% 10mm ± 10%
Set the distance 0 ~ 1.6mm 0 ~ 4mm 0 ~ 8mm
Should be poor E1,

Y1 type: less than 10% of the detection distance, D1 type: less than the detection distance of 20%
Can detect the object magnetic metal (non-magnetic metal detection distance is short.

See Catalog “characteristic data”)
Standard detection object iron 12 × 12 × 1mm iron 18 × 18 × 1mm iron 30 × 30 × 1mm

Response frequency * E1 type: 1.5kHz

D1 type: 800Hz E1 type: 600Hz 、500Hz E1 type: 400Hz、300Hz、

Y1 type: 25Hz
voltage

(Using voltage range) E1 type: DC12 ~ 24V ripple (p-p) 10% or less (DC10 ~ 30V)

Y1 type: AC24 ~ 240V (AC20 ~ 264V) 50 / 60Hz

D1 type: DC12 ~ 24V ripple (p-p) 20% or less (DC10 ~ 36V)

Current consumption E1 type: 17mA or less

Leakage current D1 type: 0.8mA or less, Y1 type: 1.7mA or less (when AC200V)

Control output switch capacity E1 type: 200mA or less,

D1 type: 5 ~ 100mA, Y1 type: 5 ~ 300mA

Residual voltage E1 type: 2V or less (load current 200mA, wire length 2m)

Y1 type: see the catalog “characteristic data”

D1 type: 3V or less (load current 100mA, wire length 2m)

Indicator E type: detection display (red), Y type: action display (red),

D type: action display (red), set display (green) (but set the display only NO type)

Action mode
(Close to the detection object) E1 type, D1 type,

Y1 type: NO For details, please refer to the catalog “Input and output section circuit diagram” timing diagram
Protection circuit

E1 type: reverse connection protection, load short circuit protection, surge absorption D1 type,

Y1 type: surge absorption
Ambient temperature range of work, save: every -25 ~ +70 ° C (no icing, condensation)

when stored: 35 ~ 95% RH (no condensation)

Temperature of ± 25 ° C at + 23 ° C in the temperature range of -25 to + 70 ° C, ± 10% of the detection distance
Voltage effect E1 type: ± 15% of the rated power supply voltage, the rated power supply voltage, the detection distance of ± 2.5%

D1 type: within ± 20% of the rated power supply voltage, the rated power supply voltage, the detection distance of ± 2.5%

Y1 type: within ± 10% of the rated power supply voltage, the rated power supply voltage, the detection distance of ± 1%

Insulation resistance 50MΩ or more (DC500V megger) The charging unit is integral with the housing
Withstand voltage E1,

D1 type: AC1,000V 50 / 60Hz 1min each charging part between the whole and the shell

Y type: AC4,000V 50 / 60Hz 1min Each charging part is integral with the shell

Vibration (durable) 10 ~ 55Hz up and down amplitude 1.5mm X, Y, Z direction 2h

Impact (durable) 500m / s2 X, Y, Z 10 times each direction 1,000m / s2 X, Y, Z 10 directions

Protection structure IEC standard IP67, the company internal standard oil

Connection type wire lead type (standard wire length 2m)
The quality (after packaging) is about 70g about 130g about 170g

Material Housing Fluorine Resin
Detection surface
Tighten nuts
Toothed Washer Galvanized
Cable PVC

Accessories manual
* Response frequency is average. Measurement conditions: the use of standard detection of objects, the detection of objects as the standard interval of 2 times the object, set the distance of 1/2 of the detection distance.
