MITSUBISHI Rotary Servo Motor HF-MP Series

Stainless Steel Washdown Food Grade

UL / CE / IP69K certifications
316L stainless steel construction
Superior to 303/304 for hygiene and corrosion resistance
FDA approved food grade components, shaft seal, and o-rings
Food-grade lubrication
Surface finish meets EHEDG and 3A criteria
Hygienic permanent markings (name plate data)
Single NFPA 79 cable for motor and absolute encoder

White Washdown Food Grade

UL / CE / RoHS / FDA / IP67 certifications
316L stainless steel construction superior to 303/304 for hygiene and corrosion resistance
FDA approved food grade components
PTFE shaft seal
Food-grade lubrication
White surface finish including flange
Stainless steel shaft, fasteners, and connectors
Corrosion proof against common cleaning & disinfecting chemicals
For applications where motor is lateral or below food
Not for direct food contact

Mitsubishi HF-MP23 Mitsubishi drive applications

1` The product has USB and RS-422 serial communication function, through the installation of the servo set software personal calculation

2` MR-J3 series of high-performance servo motor encoder with a resolution of 262144 pulse / turn

To have the ability to perform more precise control than the MR-J2S series.
3 `series of servo motors to adapt to different control needs, the encoder on the motor are supported ABS mode, as long as

4` more powerful servo set software MR-configurator use more convenient, with precise machinery
Analysis function.
Mitsubishi servo MR-J3 series features
Mitsubishi servo MR-J3 series also has the following more superior features:
High level of automatic tuning function, user-friendly;

Added robust disturbance compensation function, especially for the printing industry;

Built-in oscilloscope has three channels at the same time accurate sampling of three different sets of data, so that debugging and troubleshooting work more convenient and quick;
In line with international standards.
