KEYENCE Proximity Sensors EX-V series

KEYENCE Proximity Sensors EX-V series high-speed, high-accuracy, digital inductive displacement sensors.

Features:

    • High-speed sampling : 40,000 samples/second,resolution & accuracy due to FLL circuit
    • Automatic Bottom-dead-center measurement mode,Vibration measurement mode, Gap measurement mode
    • 2 color LED digital display for easy setup
    • Environmental resistant IP-67 sensor head
Mã: 1351-10370 Danh mục:

KEYENCE Proximity Sensors EX-V series EX-V01E

Model EX-V01E
Type Controller
Shape ø5.4 x 18 mm ø0.21″ x 0.71″ Cylindrical
Measuring range 0 to 1 mm 0.04″
A/D converting system Sequential conversion
Display range -19,999 to +19,999
Linearity ±0.3% of F.S.
Resolution (No. of averaging
measurements: 64)		 0.016 Mil 0.4 μm
Sampling rate 40,000 samplings max./sec. *1
Display speed 20 times/sec. (2-color, 7-segment LED)
Display power 7-segment 2-color LED
Over-range alarm ±FFFF is displayed.
Control input Timing input NPN open-collector or non-voltage contact signal
Reset input
Auto-zero input
Judgment output: Inhibit input
Synchronization/external settings input
Control output Setting method Upper/lower 2-level setting x 4 patterns (selectable)
Signal NPN open-collector (HIGH, GO and LOW): 100 mA max. (40 V max.)
Response time 0.075 ms (at maximum speed)
OFF-delay time 60 ms (ON/OFF selectable)
Strobe output NPN: 100 mA max. (40 V max.), Residual voltage: 1 V max. (N.O.)
Alarm output NPN: 100 mA max. (40 V max.), Residual voltage: 1 V max. (N.C.)
Analog output voltage Output voltage ±0.5 V
Impedance 100 Ω
Response time 0.075 ms (at maximum speed)
Temperature characteristics 0.07% of F.S./°C *2
Major functions FLL, digital filter, auto zero, offset, calculation, measurement mode (15 types), judgment value memory (4 sets), decimal point shift, display digit changing, display of various errors, etc.
Rating Current consumption. 240 mA max.
Power voltage 24 VDC ±10%, Ripple (P-P): 10% max.
Environmental resistance Operating temperature range 0 to +50°C 32 to 122°F, 35 to 80%RH (no condensation)
Operating ambient humidity 35 to 85%, No condensation
Vibration 10 to 55 Hz, 1.5 mm 0.06″ double amplitude for 2 hours in each of the X, Y, and Z directions
Weight Approx 235 g
