KEYENCE Photoelectric Sensors LR-T Series

KEYENCE Photoelectric Sensors LR-T series  is designed to detect at long ranges while remaining highly stable. This is achieved due to the HS2 technology used, a combination of Time of Flight detection and a custom integrated circuit. Additionally, the interference prevention and Datum Function allow users to maximize this sensors capability in any situation.

The LR-T Series is simple to install and calibrate. Flexible mounting options, a visible beam spot, push button teach, and an easy to read display allow for quick setup. Even at long distances, constant feedback is provided with the LR-T’s highly visible status indicator.

A large variety of applications are possible with the LR-T. Examples include level sensing, web tension control, and general conveyance detection.

Mã: 1351-10030 Danh mục:

KEYENCE Photoelectric Sensors LR-T series LR-TB2000

Model LR-TB2000
Type Cable
Detectable distance 60 to 2000 mm 2.36″ to 78.74″*1
Spot diameter Approx. ø4 mm ø0.16″
Response time 1 ms/10 ms/25 ms/100 ms/1000 ms
selectable
Light source Type Red laser (660 nm)
Laser class Class 2 laser product
(IEC60825-1,FDA (CDRH) Part1040.10*2)
Mutual interference prevention function 4 units (when using the interference prevention function)
Timer OFF/OFF delay/ON delay/One-shot
Power voltage 20 to 30 VDC, including 10% ripple (P-P), Class 2 or LPS
Current consumption 45 mA or less (without load)*3

The 5m (196.85”) range of the LR-T allows the sensor to be mounted away from operators or machinery keeping it out of harm’s way. Furthermore, an adjustable beam spot allows users to fine-tune the sensor from any distance.
