KEYENCE Photoelectric Sensors CZ seriesCZ-K1P Digital Fiber Optic Sensor
| Model | CZ-K1P | |||
| Output | PNP | |||
| Light source | Red LED, Green LED, Blue LED | |||
| Response time | 300 μs/1 ms (switch-selectable) | |||
| Indicator lamp | Output: Red LED, Calibration: Orange LED, External synchronization input: Green LED, Matching rate/received light intensity: LCD (Red/Green) |
|||
| Error indication | Excess light intensity, insufficient light intensity, insufficient color difference | |||
| Calibration method | 1-point/2-point calibration (switch-selectable) | |||
| Tolerance value adjustment | Numerical value setting on digital display | |||
| Differentiation mode | C mode/C + I mode/I mode (switch-selectable) | |||
| Timer function | OFF-delay timer (40 ms)/Timer OFF (switch-selectable) | |||
| External synchronization input | Response speed: 500 μs max. | |||
| External calibration input | Input response time: 20 ms min. | |||
| Registered color selection | 8-bank selection (By external input), Non-voltage input, Input response time: 20 ms min. |
|||
| Control output | PNP: 40 VDC max. (100 mA max.), Residual voltage: 1.0 V max. | |||
| Protection circuit | Reverse-polarity protection (power supply), overcurrent protection (output), surge absorber (output) |
|||
| Rating | Power voltage | 12 to 24 VDC ±10%, Ripple (P-P): 10% max. | ||
| Current consumption. | 75 mA max. | |||
| Environmental resistance | Operating ambientluminance | Incandescent lamp: 5000 lux max., Sunlight: 10000 lux max. | ||
| Operating temperature range | -10 to +55°C 14 to 131°F, No freezing*1 | |||
| Operating ambient humidity | 35 to 85% RH (No condensation) | |||
| Vibration | 10 to 55 Hz, 1.5 mm 0.06″, double amplitude in X, Y, Z directions, 2 hours respectively | |||
| Shock resistance | 500 m/s2 in X, Y, Z directions, 3 times respectively | |||
| Case material | Polycarbonate | |||
| Weight | Approx 115 g (including 2-m 6.6′ cable) | |||
