Differential pressure transmitter Honeywell the STD800 is a high performance with advanced sensor technology.
STD800 by the differential pressure and the sensor chip on the static pressure and temperature compensation can be combined in a wide range
The SmartLine series can provide the highest level of compatibility assurance and integration capabilities.
Best-in-class features:
The accuracy of the calibration range is as high as 0.0375%
Annual stability of up to 0.01% / full scale, for 10 years
Automatic hydrostatic and temperature compensation
Up to 400: 1 range ratio
Response time up to 90ms
A variety of local display functions
External zero, range and configuration functions
Power supply polarity is connected
Perfect self-diagnostic function
Based on ANSI / NFPA 70-202 and ANSI / ISA 12.27.0 integrated dual seal design to ensure maximum safety
World-class overvoltage protection
The standard is fully compliant with SIL2 / 3.
Full module design
