Honeywell DL5000 PPB/PPM balance type dissolved oxygen electrode
Overview
The DL 5000 Dissolved Oxygen probe is based on a unique equilibrium probe technology. This patented equilibrium probe technology is based on the partial pressure of oxygen rather than the
diffusion rate of oxygen through the probe membrane. The materials of construction combined
with this unique design result in a nointernal-maintenance probe that is independent of process flow and fouling because the anode is not consumed.
Bottom line—an accurate, reliable, maintenance-free, Dissolved Oxygen measurement requiring less recalibration.
Description
The DL5000 is housed in either a stainless steel or PVC casing. It can be ordered as a remote probe to be used with the UDA2182 analytical Analyzer, or an integral / remote probe for use with Direct Line DL 424 or 425 transmitters. The remote DL5000 probe can be used
with:
ƒ UDA 2182 Analyzer to replace withdrawn 7020 series units
ƒ DirectLine 424 or 425 sensor module in new installations.
Connections
Both PVC and stainless steel probes are available with an integral cable. This option provides the cable potted into the probe. The cable and cell are one entity and cannot be separated. This option can be used with all mountings. In addition to the integral cable option, the stainless steel probes are also available with a quick disconnect option. This probe comes with a Turck® receptacle potted into the top which mates with a cable. (Must be purchased from Honeywell.) The probe and cable are separate entities. This option can only be used in in-line
applications
