Pressure Transmitter
Yokogawa EJA310E Absolute Pressure Transmitter
The high performance absolute pressure transmitter EJA310E features single crystal silicon resonant sensor and is suitable to measure liquid, gas, or steam pressure. The EJA310E outputs a 4 to 20 mA DC signal corresponding to the measured pressure.
It also features quick response, remote setup and monitoring via BRAIN or HART communications and self-diagnostics.
FOUNDATION Fieldbus, PROFIBUS PA and 1 to 5 V DC with HART (Low Power) protocol types are also available. All EJA-E series models in their standard configuration, with the exception of the Fieldbus, PROFIBUS and Low Power types, are certified by TÜV as complying with SIL 2 for safety requirement.
it combines the ruggedness and success of the work-horse EJA-A series with the performance of the thoroughbred EJX-A series to deliver the type of product you have come to expect from Yokogawa.
The EJA310E is our traditional-mount absolute pressure transmitter in the series.
EJA310E standard features include:
- 0.1% Accuracy
- 0.1% Stability for 1 year
- 3,600 psia Maximum Over Pressure (MWP)
- 90 ms Response Time
- Local Parameter Setting (LPS)
- SIL 2 / SIL 3 (IEC61508) Certified
Available with HART 5/7, 1 to 5 VDC HART 7 (Low Power), FOUNDATION Fieldbus, PROFIBUS PA, or BRAIN communication.
