YTC Smart Positioner YT-2550 Series

YTC Smart Positioner YT-2550 Series

YTC Smart Positioner YT-2550 Series

YTC Smart Positioner YT-2550 Series ccurately controls valve stroke, according to input signal of 4~20mA being delivered from controller.

  • Fail freeze function
  • Near zero air consumption level
  • HART comunication
  • Auto calibration
  • PD control
  • 4 buttons for local control
  • LCD display
  • Feedback signal
  • Limit switch

models:

YT-3300-LSN ；YT-3350LSN ；YT-3300-LSI ；YT-3350LSI ；YT-3300-LDN ；YT-3350LDN ；YT-3300-LDI ；YT-3350LDI ；YT3300-RSN ；YT-3350RSN ；YT-3300-RSI ；YT-3350RSI；YT-3300-RDN ；YT-3350RDN ；YT-3300-RDI ；YT-3350RDI ；YT-3303LSN ；YT-3303LDN ；YT-3303LSI ；YT-3303LDI ；YT-3303RSN ；YT-3303RSI ；YT-3303RDN ；YT-3303RDI ；YT-3301LSN；YT-3301LSI ；YT-3301LDN ；YT-3301LDI ；YT-3301RSN ；YT-3301RSI ；YT-3301RDN ；YT-3301RDI ；YT-3400LSC；YT-3400LDC ；YT-3400RSC ；YT-3400RDC ；YT-3450LSC ；YT-3450LDC；YT-3450RSC ；YT-3450RDC ；YT-2500LSN ；YT-2500LDN ；YT-2500LSI ；YT-2500LDI ； YT-2500RSN ；YT-2500RDN ；YT-2500RSI ；YT-2500RDI ；YT-2550LSN ；YT-2550LDN ；YT-2550LSI；YT-2550LDI ； YT-2550RSN ；YT-2550RDN ；YT-2550RSI ；YT-2550RDI ；YT-2501LSN ；YT-2501LDN ；YT-2501LSI ；YT-2501LDI ；YT-2501RSN ；YT-2501RDN ；YT-2501RSI ；YT-2501RDI；YT-2600LSC ；YT-2600LDC ；YT-2600RSC ；YT-2600RDC ；YT-2700LSN ；YT-2700LSI ；YT-2700RSN ；YT-2700RSI ；

Mã: 1343-10090 Danh mục:
 YTC Smart Positioner YT-2550 Series
Item.Type YT-2500 YT-2550
Input Signal 4-20mA DC
Supply Pressure 0.14-0.7MPa(1.4-7bar)
Stroke Linear Type 10-150mm
Rotary Type 0-90°
Impedance Max.500Ω@20mA DC
Air Connection PT(NPT)1/4 NPT1/4
Gauge Connection PT(NPT)1/8 NPT1/8
Conduit PF1/2(G1/2)
Ambient Temp Operating Temp (-30°C~80°C)/(-22~176°F)
Explosion Temp (-40°C~60°C T5)/(-40°C~40°C T6)
Linearity ±0.5% F.S
Hysteresis ±0.5% F.S
Sensitivity ±0.2% F.S
Repeatability ±0.3% F.S
Air Consumption Fail Freeze 0.01LPM(sup=0.14MPa)
Fail Safe 6LPM(sup=0.14MPa)
Flow Capacity 60LPM(sup=0.14MPa)
Output Characteristics Linear,EQ%,Quick Open user set(16 Point)
Material Aluminum Diecasting Stainless Steel316
Enclosure IP66
Explosion Proof Type Exia IIC T5/T6
Weight 1.5kg(3.3Ib) 2.9kg(6.4Ib)
