ABB TEIP11 IP signal converter for standard signals

    ABB TEIP11 IP signal converter for standard signals

    The I/P converter with various housing is available for cabinet installation, field installation, rail installation and as slide-in type. The signal conversion is based on standard signals. Current signals 0/4 to 20 mA are converted to pressure signals 0.2 to 1 bar or 3 to 15 psi.

    Mã: 1341-10120 Danh mục:

    ABB TEIP11 IP signal converter for standard signals without booster stage

    Data

    General specifications:

    • Small dimensions
    • Variable designs
      – Control room housing IP 20, for rail and block mounting
      – Field housing, polyester IP 54
      – Field housing, aluminium IP 65
      – Field housing, stainless steel IP 65
    • High immunity to shocks and vibrations with an effect < 1% for loads up to 10 g
    • Wide temperature range
      –  -40 °C (optionally -55 °C) to 85 °C
    • Worldwide approvals for Explosion Proof and Intrinsic Safety
